| Model | Max Static Load (KG) |
Max Load Capacity (KG) |
SPEED (M/S) |
Roping | Sheave Dia (MM) |
Rope (MM) |
Power (HP/KW) |
Moter Specification Rated Current (A) |
Pole | Travel Height |
|---|---|---|---|---|---|---|---|---|---|---|
| SRI-05 UT | 3000 | 408 | 0.65 | 1:1 | ∅520 | 3X13 | 5/3.7 | 8.5 | 6 | 20 Meters |
| SRI-05 UT | 3000 | 408 | 1 | 1:1 | ∅520 | 3X13 | 5/3.7 | 8.5 | 6 | 20 Meters |
| SRI-05 UT | 3000 | 408 | 0.65 | 1:1 | ∅530 | 3X13 | 7.5/5.5 | 12.5 | 6 | 30 Meters |
| SRI-05 UT | 3000 | 408 | 1 | 1:1 | ∅530 | 3X13 | 7.5/5.5 | 12.5 | 6 | 30 Meters |
| SRI-05 UT | 3000 | 750 | 0.32 | 2:1 | ∅530 | 3X13 | 7.5/5.5 | 12.5 | 6 | 30 Meters |
| SRI-06 UT | 4500 | 544 | 0.65 | 1:1 | ∅530 | 3X13 | 7.5/5.5 | 12.5 | 6 | 30 Meters |
| SRI-06 UT | 4500 | 544 | 1 | 1:1 | ∅530 | 3X13 | 7.5/5.5 | 12.5 | 6 | 30 Meters |
| SRI-06 UT | 4500 | 680 | 0.65 | 1:1 | ∅530 | 3X13 | 7.5/5.5 | 12.5 | 6 | 20 Meters |
| SRI-06 UT | 4500 | 680 | 1 | 1:1 | ∅530 | 3X13 | 7.5/5.5 | 12.5 | 6 | 20 Meters |
| SRI-06 UT | 4500 | 680 | 0.65 | 1:1 | ∅530 | 3X13 | 10/7.5 | 15 | 6 | 30 Meters |
| SRI-06 UT | 4500 | 680 | 1 | 1:1 | ∅530 | 3X13 | 10/7.5 | 15 | 6 | 30 Meters |
| SRI-06 UT | 4500 | 1000 | 0.65 | 1:1 | ∅530 | 3X13 | 10/7.5 | 15 | 6 | 30 Meters |
| SRI-06 UT | 4500 | 1000 | 0.32 | 2:1 | ∅530 | 3X13 | 10/7.5 | 15 | 6 | 30 Meters |
| SRI-07 UT | 6500 | 1500 | 0.32 | 2:1 | ∅610 | 4X13 | 10/7.5 | 15 | 6 | 30 Meters |
| SRI-08 UT | 7500 | 2000 | 0.32 | 2:1 | ∅610 | 4X13 | 15/11 | 22 | 6 | 30 Meters |
| SRI-09 UT | 8300 | 2500 | 0.32 | 2:1 | ∅610 | 4X13 | 15/11 | 22 | 6 | 30 Meters |
| SRI-09 UT | 8300 | 3000 | 0.32 | 2:1 | ∅610 | 5X13 | 20/15 | 30 | 6 | 30 Meters |
